225296 12V 40A Waterproof 4Pin Automotive Relay Orange Cover For Car / Truck 3171420 1504951 0 332 014 150 0 332 014 203

    Buy cheap 225296 12V 40A Waterproof 4Pin Automotive Relay Orange Cover For Car / Truck 3171420 1504951 0 332 014 150 0 332 014 203 from wholesalers

    Buy cheap 225296 12V 40A Waterproof 4Pin Automotive Relay Orange Cover For Car / Truck 3171420 1504951 0 332 014 150 0 332 014 203 from wholesalers
    • Buy cheap 225296 12V 40A Waterproof 4Pin Automotive Relay Orange Cover For Car / Truck 3171420 1504951 0 332 014 150 0 332 014 203 from wholesalers
    • Buy cheap 225296 12V 40A Waterproof 4Pin Automotive Relay Orange Cover For Car / Truck 3171420 1504951 0 332 014 150 0 332 014 203 from wholesalers
    • Buy cheap 225296 12V 40A Waterproof 4Pin Automotive Relay Orange Cover For Car / Truck 3171420 1504951 0 332 014 150 0 332 014 203 from wholesalers

    225296 12V 40A Waterproof 4Pin Automotive Relay Orange Cover For Car / Truck 3171420 1504951 0 332 014 150 0 332 014 203

    Ask Lasest Price
    Brand Name : Mirote
    Model Number : HY412-A
    Price : Negotiation
    Payment Terms : L/C, T/T, MoneyGram, Western Union
    Supply Ability : 500000pcs/Month
    Delivery Time : 20-35 WORK DAYS
    • Product Details
    • Company Profile

    225296 12V 40A Waterproof 4Pin Automotive Relay Orange Cover For Car / Truck 3171420 1504951 0 332 014 150 0 332 014 203

    12V 40A Waterproof 4 Pin Automotive Relay JD1912 Orange Cover For Car / Truck

    EXPORT LOGO & DOMESTIC LOGO

    225296 12V 40A Waterproof 4Pin Automotive Relay Orange Cover For Car / Truck 3171420 1504951 0 332 014 150 0 332 014 203 225296 12V 40A Waterproof 4Pin Automotive Relay Orange Cover For Car / Truck 3171420 1504951 0 332 014 150 0 332 014 203


    When you opened this website which means we are very lucky get your attention , your visiting is very important for us . We are the most abundant manufacturer of relay and flasher products in China , competitive price .We sincerely hope to cooperate with you, an important customer , to create higher value and future together .

    1.How to choose a good relay ,

    its quality mainly depends on the material and technology, choose a silver contact point makes the working life much longer, and machine core use pure copper wire, 30 and 87 pins use copper material too, then the relay can be used for 5-8 years. If add one more braided wire ,the power will be larger, so as the working life . If need matching with the OEMs , you can choose a larger particles of silver contact , using longer, but the price will be higher too .Our company has been established for over ten years. More than 100 kinds of products in our factory production , almost contain all car relays and flasher, welcome to consult.


    Zhejiang Huiyou is a factory in China for more than ten years. Its products are sold to more than 30 countries and regions all over the world. It has a strong technical reserve, excellent automation production equipment and more than 100,000 products are shipped every day. Strict quality management team, sincerely looking forward to partners from around the world.

    225296 12V 40A Waterproof 4Pin Automotive Relay Orange Cover For Car / Truck 3171420 1504951 0 332 014 150 0 332 014 203


    2. Breif Introduction



    225296 12V 40A Waterproof 4Pin Automotive Relay Orange Cover For Car / Truck 3171420 1504951 0 332 014 150 0 332 014 203225296 12V 40A Waterproof 4Pin Automotive Relay Orange Cover For Car / Truck 3171420 1504951 0 332 014 150 0 332 014 203225296 12V 40A Waterproof 4Pin Automotive Relay Orange Cover For Car / Truck 3171420 1504951 0 332 014 150 0 332 014 203225296 12V 40A Waterproof 4Pin Automotive Relay Orange Cover For Car / Truck 3171420 1504951 0 332 014 150 0 332 014 203225296 12V 40A Waterproof 4Pin Automotive Relay Orange Cover For Car / Truck 3171420 1504951 0 332 014 150 0 332 014 203

    3.Parameter


    Contact Data

    Contact Form1A 1C
    Contact MaterialAgCdO
    Contact Resistance<100MΩ
    Max Switching Current40AMP
    Rated Load40A /14VDC
    Coil Voltage3~24V
    Coil Power1.8W

    Technical Specifications

    Insolution Resistance>100MΩ (500 VDC)
    Dielectrical Strength ( between coil and contact )>1000 VAC
    Operate Time<10MS
    Release Time<5MS
    Mechanical Life1x107
    Electrical Life1x105
    Install ModelScrew / Plug

    4.Excellent production equipment, more than 100,000 pieces per day, super fast delivery speed

    225296 12V 40A Waterproof 4Pin Automotive Relay Orange Cover For Car / Truck 3171420 1504951 0 332 014 150 0 332 014 203

    5.Twenty exhibitions worldwide each year

    225296 12V 40A Waterproof 4Pin Automotive Relay Orange Cover For Car / Truck 3171420 1504951 0 332 014 150 0 332 014 203

    6.More than 100 products

    225296 12V 40A Waterproof 4Pin Automotive Relay Orange Cover For Car / Truck 3171420 1504951 0 332 014 150 0 332 014 203

    7.Application

    Mainly used for headlamp and air-conditioner of universal cars .


    8. Product packaging

    Nowadays, package is important, we have various packing methods for your selection.

    225296 12V 40A Waterproof 4Pin Automotive Relay Orange Cover For Car / Truck 3171420 1504951 0 332 014 150 0 332 014 203


    You can also customize your package, as long as the quantity is considerable.


    9.Guarantee

    To make you rest assured about the after-sale,we would like to provide one-year quality guarantee.


    10.Terms of payment
    T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.

    11.Terms of delivery

    FOB, CFR, CIF,

    12. Delivery time
    Generally, it will take 15 to 30 work days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.

    We are the manufacturer of auto parts for more than 10 years, definitely we can provide you with good quality, good price and good service.
